Our Association

We are an authorised distributors of Agru, Ashiward by aliaxis, and KSB Valves.

Engineer, procure, and construct thermoplastic piping systems in Pune

DeltaFlow being an EPC specialist in Pune has been supplying supreme-quality, leak-free, non-corrosive, non-rusting, high-pressure, and temperature-tolerant thermoplastic pipelines, and tanks to various clients. We have provided our service to more than a thousand clients, and they are happy with our products. Contact us to get a complete guide, from the thermoplastic piping systems design, selection of materials to installation, repair, and replacement work. Engineering, Procurement, and Construction Services Pune is not easy, and only experts can do it so DeltaFlow is the only name in industrial piping systems. Our expert team have several years of experience that enable them to provide even better services now and in the future. We also offer thermoplastic tanks, ducting fabrication, and installation. Our case to case basis piping design, supply, and installations are perfect for customers who want customized services. Get in touch with us today for our products and services.

Reinforced Thermoplastic Pipe Materials

  • PVC-U Piping System with reinforced thermoplastic pipe

    The reinforced thermoplastic pipe system made of PVC-U material can be used for operating temperatures in the range of 0°C to +60°C. Thanks to outstanding chemical resistance, PVC-U piping systems withstand demanding conditions, particularly during the transport of aggressive media, such as acids, bases and salts. The thermoplastic PVC-U piping system is used primarily in the chemical and textile industries, in water treatment and drinking water purification as well as in vacuum lines.

    Nominal pressure Up to 16 bar Temperature range 0°C to +60°C
    Reinforced Thermoplastic Pipe Materials: UPVC Unplasticized Polyvinyl Chloride
    Joining technology used is Solvent cementing. Generally, this pipe and fittings are available in grey color.

  • PVC –C Piping System

    CPVC piping system meeting all challenging application requirement of thermoplastic piping systems can be used upto 93°C temperature & pressure up to 16 bar based on the pipe sizes.

    CPVC thermoplastic industrial piping system is suitable for many industrial requirements like metal treating, pulp & paper, food & beverages, industrial waste water, Chemical processing etc.

    We provide Industrial Grade Chlorinated Polyvinyl Chloride (CPVC) Pipes of schedule 40 & 80 and fittings of schedule 80 confirm to ASTM Standards ranging from 1.5 cm (½”) to 30.0 cm (12”). Electrofusion pipe jointing machine technology used is Solvent cementing. Generally this pipe and fittings are available in grey color.

  • PE(HDPE) reinforced thermoplastic pipe System

    HDPE pipe is a type of flexible plastic pipe used for fluid and gas transfer and is often used to replace ageing concrete or steel mains pipelines. Made from the thermoplastic HDPE (high- density polyethylene, its high level of impermeability and strong molecular bond make it suitable for high pressure pipelines. HDPE pipe is used across the globe for applications such as water mains, gas mains, sewer mains, slurry transfer lines, rural irrigation, fire system supply lines, and stormwater and drainage pipes.

    Two types of PE material pipe and fittings are generally used in market are PE80 & PE100.
    Nominal pressure Up to 16 bar Temperature range Up to -20°C to +60°C
    Joining technology used is Butt Fusion or Electrofusion type.

  • PP-H - thermoplastic piping systems design

    Polypropylene Homo-Polymer (PPH) is a thermoplastic from the polyolefin cluster. PPH Piping System is a semi-rigid, apparent chemical compound with good toughness and weather-resistance properties, less moisture absorption, Excellent resistance against abrasion

    Useful for several aggressive chemical , hi purity water and acids. PPH fitting flexibility and weldability make it easier and more cost-effective to install, as well as more secure.

    Nominal pressure Up to 16 bar Temperature range Up to 0°C to +90°C
    Joining technology used is Butt Fusion, Socket Fusion or IR Fusion.

  • PVDF Thermoplastic Piping Systems

    Our PVDF thermoplastic pipe and fittings are excellent for handling a wide range of chemical solvents and materials since they are resistant to reacting with most of these substances. Among the most often used commercial and industrial PVDF thermoplastic pipes are polyvinylidene fluoride pipes and fittings. The material is highly resistant to the majority of organic and inorganic media PVDF is used as piping, sheet, and internal coatings in high-temperature, hot acid, radiation environment applications

    It's often used in the semiconductor, chemical, medical and high corrosive chemical like bromine and other aggressive media.

    Nominal pressure Up to 16 bar Temperature range Up to -20°C to 140°C
    Joining technology used is Butt Fusion, Socket Fusion or IR Fusion & BCF (Bead and Crevice Free)

The engineers at DeltaFlow follow the various standard given by commercial, industrial, and governmental sectors to design the perfect thermoplastic piping design and detailing. We refer to the specifications set by ASTM Standards. These standards also help us to provide a case to case basis piping design, supply, and installations and modify certain parts. Below you will find a list of standards that engineers mostly use for industrial thermoplastic piping systems design.

  • CPVC: Thermoplastic piping systems design

    - PIPES:SCH 40 & 80: as per ASTM F441
    - FITTINGS: SCH 80 : as per ASTM F439

  • UPVC: Thermoplastic piping systems design

    - ASTM D 1784- Rigid Poly Vinyl Chloride(PVC) Compounds.
    - ASTM D 1785- Poly Vinyl Chloride (PVC) Plastic Pipes, SCH 40 & SCH 80.
    - ASTM D 2466- Socket type Poly Vinyl Chloride (PVC) Plastic Pipe Fittings, SCH 40.
    - ASTM D 2467- Socket type poly Vinyl Chloride (PVC) Plastic Pipes Fittings, SCH80.

  • PP-H and PVDF: Thermoplastic piping systems design

    - DIN EN ISO 17855-1:2015-02
    Plastics - Polyethylene (PE) moulding and extrusion materials
    - DIN EN ISO I 9069-1:2015-06
    Plastics - Polypropylene (PP) moulding and extrusion materials

    - DIN 4102
    Fire behaviour of building materials and building components
    - ISO 4065
    Thermoplastic pipes
    - ISO 10931 part 1 - part 5
    thermoplastic piping systems design for industrial applications - Polyvinylidene fluoride (PVDF)

We offer frequent cleaning of duct systems that extract dust from machines. It contains special transitions connecting the collector to the ductwork. Our thermoplastic tanks, ducting fabrication, and installation can collect dust from any angle, keeping the tanks and pipelines dust-free.

Our case to case basis piping design, supply, and installations enable you to avail of basic or customized duct fabrication. We supply products keeping in mind the specifications of our clients. You can call us for a top-quality yet affordable duct system.

Thermoplastic Piping System Design

Conclusion - Thermoplastic piping systems design

We have covered the various materials and standards of thermoplastic piping systems design and tanks we supply. Our duct fabrication can also help you remove all dust from industrial equipment. Often dust can cause a hindrance to the smooth and efficient working of your pipelines or cause blockages in tanks. You need to spend a huge amount on the repair or replacement of your pipelines and tanks. Also, wrong material or not adhering to specified standards can cause trouble in the daily work of your industry.

Case to case basis piping design, supply, and installations can provide you with the right choice to make your equipment last longer. Customized installations are affordable and enhance the effectiveness of production. So, are you ready to install leak-free pipelines and tanks in your industry? Get in touch with DeltaFlow for any problem or requirements related to thermoplastic piping systems and tanks.

Do it all with DeltaFlow

Are you confused about how to choose leakage-free, non-corrosive pipelines and tanks for your industry?

We know how difficult it is to choose the right material and type of tanks and pipelines that will last for years without you having to face any trouble. Delta Flow is the number one supplier of leakage-free, non-corrosive, non-rusting thermoplastic piping design & detailing and thermoplastic tanks as per DVS standards. Our pipes and tanks can withstand heavy stress and temperature. So, contact us for the selection of material, jointing, and testing as per application 3D modeling with design for piping systems.
